Description:
FEATURESSky panels bring in the dream-like nature of the sky to your office or home.
The sky peanel are ideal for conference rooms, churches, day cares, nursing homes, hospitals,workout rooms and gymnasiums. They are easy to install and can fit in any drop ceiling. An optional surface mount kit is also available.
The back lite panel are used with OSRAM led as light source and Mitsubish PMMA as LGP witch insure the high quality of light output upto 90lm/w, average 5000lx on surface .
Printing direct on acrylic sheet
SPECIFICATION
Voltage. : 12V/24VDC
Watt.: 48W/sqm
Operating Temperature: 0-45
Light span: 50000hrs/70%
Available: 2700-6500K
CRI: >80
Lumen: 80-90lm/w
Waterproof Degree: IP20
Max size: 1000 x 1000mm at CH012 frame
Other biger size: doable on request such as 1500x2000mm , 1500x1500mm
APPLICATION
T-Grid Ceiling
Office
Healthcare
Retail store
Corridors
